Electro-Voice EKX-15P
€ 895
Matching accessories:
- EV EKX 15P
- 15" 2-way active speaker
- Class D amplifier
- Intelligent thermal management
- Compact and durable design
- Intuitive menu
Electro-Voice EKX-15P Active Speaker
EV EKX-15P is a 15? 2-way active speaker with wood enclosure and EVCoat coating, providing a compact and durable design. The speaker has intuitive menu with navigation via LCD, as well as QuickSmartDSP features.
Class D amplifier
With a 1500 W Class D amplifier, the EV EKX 15 P can deliver up to 134 dB of sound.
Intelligent thermal management
Electro-Voice The EKX-15P has built-in intelligent thermal management with fan function, ensuring optimum reliability and long-lasting performance.
| Model/Product no.: | EV-EKX-15P |
| GTIN | 800549772181 |
| Weight (kg) | 24,4 |
| Color | Black |
| Size | 15" |
| Monitor direction | Yes |
| Type | Two-way |
| Microphone input | No |
| DSP | Yes |
| Bluetooth | No |
| Material | Wood |
Specifications | |
| Connector Type | (1) Stereo RCA input, (2) XLR/TRS combo jack, and (1) XLR link output |
| Coverage (Nominal -6 dB) H | 90 ° |
| Coverage (Nominal -6 dB) V | 60 ° |
| Crossover Frequency | 1.7 k Hz |
| Enclosure Material | 15 mm, plywood with EVCoat |
| Frequency Response (-10 dB) | 48 Hz - 20 kHz Hz Full space measurement using the music DSP preset |
| Frequency Response (-3 dB) | 55 Hz - 18 kHz Hz Full space measurement using the music DSP preset |
| Grill | 18 AWG steel with powdercoat |
| HF Transducer | DH-1M 1-inch titanium compression driver |
| LF Transducer | EVS-15M 381 mm (15 in) |
| Maximum SPL | 134 dB Maximum SPL is measured at 1 m using broadband pink noise at maximum output |
| Power Consumption | 1.8 A Current rating is 1/8 power |
| Power Rating | 1500 W |
| Shipping Weight | 29.5 kg (65.04 lbs) |
| Suspension | (8) M10 threaded mounting points |
| Height | 16RU 685 mm (26.97") |
| Width | 432 mm (17.01") |
| Depth | 429 mm (16.89") |
| Weight Net | 24.4 kg (53.79 lbs) |
