EUROLITE LED KLS Laser Bar Next FX Sound Set

• Portable light kit with laser, LED heads, spots and strobes.
• Easy mounting with rotating bracket.
• Lots of effects and settings in user-friendly format.

EUROLITE LED KLS Laser Bar Next FX Sound Set

• DMX light effectable with laser, 2 rotating LED heads, 4 spots and UV strobe lights.
• 2 laser diodes with hundreds of green and røde beams.
• 2 rotating heads with fire LEDs (red, green, blue and warm white) each.
• 4 UV LED strobes.
• Lightweight and good for mobile use.
• Easy truss and crossbar mounting.
• Auto, music, master/slave and DMX mode.
• New software design with smart programming.

• Power supply: 100-240 V AC, 50/60 Hz
• Power consumption: 90 W
• IP classification: IP20
• Protection class: Class I
• Power connection: Mains input P-Con (blue), mounting version Power supply cord with safety plug (provided)
• Cable construction: 3 x 1.0 mm² H05VV-F
• Cable length: 3 m
• Power output: 1 x P-Con (gray), mounting version
• Fuse: T 1 A Fuse replaceable
• Lamp type: LED lamp
• LED: Spot 3 x high-power 4 W 4in1 QCL RGB/WW (homogenous color mix)Multi beam effect 4 x high-power 3 W RGB/WWStrobe effect 4 x high-power 1.5 W UV
• Flash rate: 0 - 30 Hz
• DMX channels: 6; 8; 11; 21; 25; 29
• DMX input: 1 x 3-pin XLR (M) mounting version
• DMX output: 1 x 3-pin XLR (F) mounting version
• Cooling: Cooling fan
• Control: QuickDMX via USB (optional); DMX; Stand-alone; Sound to light via Microphone; IR remote control; Wireless footswitch (optional)
• Beam angle: 7°
• Beam angle (1/2 peak): Spot 7°
• Beam angle (1/10 peak): Spot 20°
• Housing color: Black
• Attachment system: TV spigot Ø 28mm
• Dimension:  Width: 1.11 m, Depth: 11 cm, Height: 41 cm
• Weight: 10.50 kg
• Noise classification: Class 2 (slight noise)

Laser

• Laser class: Class 2M
• Laser color:    RG
• Laser module:    R red 100 mW 650nmG green 30 mW 532nm

Remote control

• Battery:  Button cell 3.0 V CR2025 lithium manganese built-in

Package contents

• 1 x device
• 1 x user manual
• 1 x power cord
• 1 x bag
• 1 x declaration of conformity
• 1 x remote control
• 2 x mounting bracket
• 2 x knurled screw
• 2 x washer
• 1 x terminating plug (power)
