Description
Description
- 96kHz FPGA processing
- 48 Input Channels
- DEEP Processing ready
- 17 Faders / 6 Layers
- 12 Stereo mixes + LR
- 3 Stereo Matrix
- 8 Stereo FX Engines + dedicated returns
- 7" capacitive touchscreen
- SLink port for remote audio / expansion
- 64ch I/O Port for audio networking
- 32×32 USB audio interface
- SQ-Drive direct recording to USB
- AES output
- Chromatic channel metering
- Integrated LED illumination
- Dedicated physical controls
- 8 Assignable SoftKeys
- Channel LCD displays
- 19" rack mountable
- Compatible with the ME 1 and ME-500, as well as Dante or Waves audio networking cards
- Dimensions: 440 x 514.9 x 198 mm
- Weight: 10.5 kg
Specifications
Specifications
-
Weight (kg)
More specifications
More specifications
Brand: Allen & Heath
SKU: LP-AH-SQ5-DIGIMIX-37SQ-5
