Alto TrueMix 800FX

• An easy-to-use mixer with built-in DSP effects from Alto
• Loads of impressive features
• Many options for connectivity

Alto TrueMix 800FX

• Alto Professional TrueMix 800 FX is a compact mixer with built-in DSP effects that gives you everything you need for recording, live streaming, podcasting or performing.
• With 16 effects from Alesis, including chorus, flanger and various delays and reverbs, you get high-quality sound.
• The mixer's Bluetooth channel supports feedback-free phone pairing thanks to "mix-minus" technology.
• There are 8 high headroom analog inputs, 4 of which are microphone inputs with XLR connections and 48v phantom power.
• The two stereo input channels have dual balanced TRS inputs.
• TrueMix 800 FX also offers USB connectivity for plug and play on both Windows and macOS.
• With fire headphone outputs and flexible output routing, the mixer's sound can be customized to suit any need.

• Compact analog mixer with 8 channels, BlueTooth and 16 effects
• USB I/O for audio playback and stereo recording
• Dedicated bluetooth channel with "mix-minus" for feedback-free phone pairing
• 4 headphone outputs with independent volume control
• 16 built-in Alesis multi-effects with dedicated return channel
• TRS Main, Tape and AUX outputs
• 4 microphone input channels with phantom power and balanced line inputs
• 2 stereo input channels with balanced 1/4" TRS connectors
• Two-band EQ on all channels
• 2-track inputs with separate routing: Main Mix or headphone output
• 8-segment LED VU meter
• Extra button caps included in the box
• Frequency response: 20 Hz - 22 kHz (±1 dB)
• THD+N: < 0.005% (@ 4 dBu, 1 kHz)
• Gain range: Microphone inputs (Channel 1-2): 0 - 50 dB, Line inputs (Channel 1-2): 15 dBu - 35 dBu, Line inputs (Channel 3-6): -20 dBu - +20 dBu
• Max voltage gain: 70 dB (MIC INPUT to MAIN MIX OUTPUT), 80 dB (MIC INPUT to CTRL ROOM / PHONE OUTPUT), 60 dB (MIC INPUT to MON SEND)
• SNR: > 110 dBu
• Crossover Frequency: Adjacent inputs: < -80 dB @ 1 kHz, Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, channels 1-2, panned hard left or right)
• Phantom Power: +45 ~ +49V with on/off button
• Impedance: Mic inputs: 3.9 k, All other inputs: > 10 k, Aux outputs: 1 k, All outputs: 120
• Equalizer: High: ±15 dB @ 12 kHz, Low: ±15 dB @ 80 Hz
• Bluetooth: A2DP, Bluetooth 5.0, 2402 MHz - 2480 MH, Range: 30.5 m
• Connectors: 6 1/4" TRS outputs, 6 1/4" TRS stereo L/R inputs, 4 1/4" TRS headphone outputs, ) 1/4" TRS mono inputs, 1 Standard RCA L/R input, 1 Standard RCA L/R output, 4 XLR inputs, 1 USB type-B input, 1 DC power input
• Power: DC connection, Voltage: 18V, 1.2A, 18W consumption
• Dimensions: 305 x 238.5 x 79 mm
• Weight: 2.04 kg
